Zyxel GS1005HP 5-port Gigabit Unmanaged PoE+ Switch,

GS1005HP

The Zyxel GS1005HP/GS1008HP GbE Unmanaged PoE Switch is equipped with 5 or 8 Gigabit Ethernet ports, 4 of which are PoE ports that can deliver up to 60 w of total PoE budget  The GS1005HP/1008HP can easily connect with PoE ready devices to your network with plug-and-play design and provides power-saving benefits without compromising performance. The GS1005HP/1008HP fills a long-standing hole in the market for unmanaged PoE switches that feature the 802.3at standard, have a high power budget and are affordable for SOHOs and small businesses.

Technical Specification
Data Sheet
Inquire Now

Product Highlights


  • 60 watts of total output on 4/8 Gigabit PoE+ ports
  • LED indicators for PoE budget management
  • Fast Gigabit connection
  • Advanced energy-savings


Technical Specifications



Switch housing

  • Metal

Interface

  • 5 RJ-45 10/100/1000 Mbps Ethernet ports with auto MDI/MDIX support

PoE Ports (RJ45)

  • Standard: 802.3af and 802.3at compliant
  • 4 PoE+ ports(Port1- Port4), up to 30W per port
  • Total PoE Budget : 60W

LED Indicator

  • PWR: Power
  • PoE MAX:
    • Amber: PoE power output over 50W (total budget 60W)
  • Per port: Link/Activity
    • Amber: 10/100 Mbps
    • Green: 1000 Mbps
  • Port1- Port4: PoE+
    • Green: PoE supported

Power Supply

  • AC-to-DC external power adapter
  • Input: 100-240 V AC, 50/60 Hz

Power Consumption

  • Max. power consumption (watt): 71.99
  • Min. power Consumption (watt): 0.825

Standard

  • IEEE 802.3 10BASE-T Ethernet
  • IEEE 802.3u 100BASE-TX Fast Ethernet
  • IEEE 802.3ab 1000BASE-T Gigabit Ethernet
  • IEEE 802.3 Nway auto-negotiation
  • IEEE 802.3x full duplex operation and flow control
  • IEEE 802.3az Energy Efficient Ethernet

Performance

  • Data transfer rate (half duplex/full duplex):
    • Ethernet: 10/20 Mbps
    • Fast Ethernet: 100/200 Mbps
    • Gigabit Ethernet: 1000/2000 Mbps
  • MAC address table: 2 K
  • Memory buffer: 128 KB
  • Switching fabric (non-blocking): 10 Gbps

Features

  • Compatible With IEEE 802.3af and 802.at Compliant PDs
  • Auto-MDI/MDIX in all ports
  • EEE802.3x Flow Control
  • IEEE 802.1p QoS
  • Jumbo frame support up to 9 KB
  • Item dimensions (WxDxH): 121 x 75 x 26 mm (4.76"x2.95"x1.02")
  • Item weight: 235g (0.52 lb.)
  • Packing dimensions (WxDxH): 210 x 132 x 78 mm (8.27"x5.20"x3.07")
  • Packing weight: 834g(1.84 lb.)
