Zyxel AX5400 WiFi 6 Dual-Radio NebulaFlex Pro Outdoor Access Point WAX655E

WAX655E


Designed to combat congested mobile data networks and bad WiFi offloading, the Zyxel WAX655E access point provides multi-gigabit wireless connectivity in large open areas, such as stadiums and parking lots.

Fully equipped with the latest WiFi 6 technologies, the WAX655E is able to provide both superb performance and user satisfaction in public environments.


Product Highlights


  • 802.11ax dual radio outdoor AP delivers blazing-fast speeds up to 5400 Mbps
  • Designed for harsh outdoor environments with up to IP67 industrial-grade weather proofing
  • Obtain multi-gigabit performance with a 2.5 Gbps PoE port to support the demand for better outdoor WiFi
  • Smart Mesh automatically forms dynamic wireless links to bridge networks for interbuilding settings and mitigates complex, inconvenient cabling WiFi deployments
  • NebulaFlex Pro offers the full flexibility for users to easily switch between Nebula cloud-managed,
  • controller-managed, and standalone modes







Technical Specification
Data Sheet
Inquire Now
  • Standard: IEEE 802.11 ax/ac/n/g/b/a
  • MIMO: MU-MIMO
  • Wireless speed: 2.4 GHz 575 Mbps |5 GHz 4800 Mbps
  • Frequency band: 2.4 GHz • USA (FCC): 2.412 to 2.462 GHz
    • Europe (ETSI): 2.412 to 2.472 GHz
  • 5 GHz • USA (FCC): 5.15 to 5.35 GHz; 5.470 to 5.850 GHz
    • European (ETSI): 5.15 to 5.35 GHz; 5.470 to 5.725 GHz
  • Bandwidth: 20-, 40-, 80- and 160-MHz
  • Conducted: typical transmit output power*1
  • US (2.4 GHz/5 GHz) 24/28 dBm
  • EU (2.4 GHz/5 GHz) 18/25 dBm
  • Antenna type: 4x4 + 2x2, 6 N-type connectors*2
  • Minimum receive sensitivity: Min. Rx sensitivity up to -101 dBm
  • Band steering: Yes
  • WDS/Mesh*3: Yes
  • Fast roaming: Pre-authentication, PMK caching and 802.11r/k/v
  • DCS: Yes
  • Load balancing: Yes
  • Advanced cellular coexistence: Yes
  • Encryption: WEP/WPA/WPA2-PSK/WPA3
  • Authentication: WPA/WPA2/WPA3-Enterprise/EAP/IEEE 802.1X/RADIUS authentication
  • Access management: L2-isolation/MAC filtering/Rogue AP detection
  • IPv6: Yes
  • VLANs: Yes (Doesn’t support traffic shaping in NCC)
  • WMM: Yes
  • U-APSD: Yes
