Ubiquiti UniFi Switch 48
Managed Gigabit Switches with SFP
Available with 24 or 48 RJ45 Gigabit ports, the UniFi® Switch is a fully managed Gigabit switch, delivering robust performance and intelligent switching for your growing networks.
• Powerful Enterprise Switch Models
• Multi-Site Management
• Optical Fiber Backhaul
• Non-Blocking Throughput
• Switching Capacity
• Versatile Mounting Options
• Dimensions: 443 x 43 x 286 mm (17.44 x 1.69 x 11.26")
• Weight: 3.56 kg (7.85 lb), 3.65 kg (8.06 lb) with rack-mount bracket
• Networking Interface: (48) 10/100/1000 Mbps RJ45 Ethernet Ports(2), 1/10 Gbps SFP+ Ethernet Ports(2), 1 Gbps SFP Ethernet Ports
• Management Interface: (1) RJ45 Serial Port Out of Band (Reserved for Future Use), Ethernet In Band
• Total Non-Blocking Throughput: 70 Gbps
• Switching Capacity: 140 Gbps
• Forwarding Rate: 104.16 Mpps
• Power Method: 100 240VAC/50 60 Hz, Universal Input
• Power Supply: AC/DC, Internal, 56W DC
• Max. Power Consumption: 56W
• Sound Level: Fan Level 0: 34 dBa; Fan Level 1: 37 dBa
• Mounting: Yes, 1U High
• Operating Temperature: -5 to 40° C (23 to 104° F)
• Operating Humidity: 5 to 95% Noncondensing
• Certifications: CE, FCC, IC
