Ubiquiti UniFi CloudKey Enterprise

CK-Enterprise


A UniFi Console designed for managing massive-scale UniFi Networks.

Manage 1,000+ UniFi Network devices and 10,000+ clients

(1) 10G SFP+ and (1) GbE RJ45 LAN port

(2) 550W redundant power supply units (PSUs)

Full 1U form factor

Bluetooth for instant setup

Technical Specification
Data Sheet
Inquire Now

Dimensions
787 x 43.7 x 481.4 mm (31 x 1.7 x 19")
UniFi Application Suite


Network


✓
Managed UniFi Devices
1,000
Simultaneous Users Connected
10,000
Port Layout

1 GbE RJ45
2 (1G/100M/10M)
10G SFP+
1 (10G/1G)
Form Factor
Rack Mount (1U)
Redundancy
(2) Hot-Swappable PSUs

Networking
All Traffic Flows
—


Hardware
Max. Power Consumption
190W
Power Method
Universal AC input, 100-240V AC, 7A Max., 50/60 Hz
Power Supply
(2) Hot-Swappable AC/DC 550W PSU
Supported Voltage Range
Universal AC input, 100-240V AC, 7A Max., 50/60 Hz
Heat Dissipation
648 BTU/hr
Processor
16-core Intel® Xeon®-SP Gold 5218 at 2.3 GHz
System Memory
(2) 16 GB
On-board Storage
(1) 256 GB, M.2 2280 SATA
Weight
13.1 kg (28.9 lb)
Enclosure Material
Front panel: Aluminium Chassis: SGCC steel
Mount Material
SGCC steel
LCM Display
1.3" touchscreen
Management
Ethernet Bluetooth
LEDs

Ethernet
✓
SFP+
✓
CRPS
✓
Button
Factory Reset
ESD/EMP Protection
Air: ± 15kV, contact: ± 8kV
Ambient Operating Temperature
0 to 35° C (32 to 95° F)
Ambient Operating Humidity
8 to 90% noncondensing
NDAA Compliant
✓
Certifications
CE, FCC, IC

Software
Application Requirements

UniFi Network
Version 7.3.83 and later
