Ubiquiti UISP Power

Dimensions

289 x 280 x 52 mm (11.38 x 11.02 x 2.05")

Weight

1.4 kg (3.1 lb)

Enclosure materials

Polycarbonate, acrylonitrile butadiene styrene

Hardware

Networking interface

(1) 10/100 MbE RJ45 LAN port

Management interface

Ethernet In-band
Bluetooth

Power TransPort output

27V DC, 100W (with 1 power adapter)
27V DC, 200W (with 2 power adapters)

Power method

(2) 27V DC, 4.4A power adapters (120W Power TransPort Adapter not included)

Backup power

(1) 25.2V DC, 7.93A rechargeable Li-ion battery pack (included)
(1) 24V DC, 8.33A lead acid battery input* (battery not included)
*Connect to a lead-acid battery only. Using another battery type could be hazardous.

Max. power consumption

3W (excludes Power TransPort output and battery charger)

ESD/EMP protection

Air: ± 15 kV, contact: ± 8 kV

Ambient operating temperature

-5 to 40° C (23 to 104° F)

Ambient operating humidity

5 to 95% non-condensing

Certifications

CE, FCC, IC

NDAA Compliant

Yes

LEDs

System

Status

RJ45 data port

Link/activity

Power TransPort

On/Off

Compatibility

Supported models

UISP Console
UISP Router (installed with UISP Box)
UISP Router Pro
UISP Switch (installed with UISP Box)
UISP Switch Pro

Software

Management application

UISP: Version 1.4.5 and later
