Ubiquiti UISP airMAX Rocket Prism 5AC

Dimensions

88 x 40 x 230 mm (3.5 x 1.6 x 9.1")

Weight

400 g (14.1 oz)

Enclosure material

Die-cast aluminum

Mounting

Pole mounting (Kit included)

Wind loading

342.5 N at 200 km/h (77 lbf at 125 mph)

Hardware

Networking interface

(1) GbE RJ45 port

RF connectors

(2) RP-SMA (Waterproof)
(1) GPS (Waterproof)

Power method

Passive PoE 2-pair (4, 5+; 7, 8 return)

Power supply

24V, 1A gigabit PoE adapter (Included)

Supported voltage range

18—27V DC

Max. power consumption

9.5W

LEDs

(4) Signal strength: software-adjustable to correspond to custom RSSI levels
GPS, LAN, power

Shock and vibrations

ETSI300-019-1.4

Ambient operating temperature

-40 to 80° C (-40 to 176° F)

Ambient operating humidity

5 to 95% noncondensing

Certifications

CE, FCC, IC, RoHS

NDAA Compliant

Yes

Software

Modes

Access Point, station

Channel sizes
PtP mode
PtMP mode

10/20/30/40/50/60/80 MHz
10/20/30/40 MHz

Services

Web server, SNMP, SSH server, telnet , ping watchdog, DHCP, NAT, bridging, routing

Utilities

airMagic, airView, antenna alignment tool, discovery utility, site survey, ping, traceroute, speed test

Distance adjustment

Dynamic Ack and Ackless mode

Power adjustment

Software adjustable UI or CLI

Security

WPA2 AES only

QoS

Supports packet level classification WMM and user customer level: High/Medium/Low

Statistical reporting

Up time, packet errors, data rates, wireless distance, Ethernet link rate

Ubiquiti specific features

30/50/60 MHz Channels, airMAX ac mode, traffic shaping with burst support, discovery protocol, frequency band offset, Ackless mode

Operating Frequency (MHz)

Worldwide

5150–5875 MHz

USA
U-NII-1:
U-NII-2A:
U-NII-2C:
U-NII-3

5150–5250 MHz
5250–5350 MHz
5470–5725 MHz
5725–5850 MHz

Management Radio (MHz)

Worldwide

2412–2472 MHz

USA

2412–2462 MHz
