Ubiquiti UISP airMAX NanoBeam 5AC
High-Performance airMAX® ac Bridge
Incorporating innovative industrial design with proprietary airMAX® ac technology, the NanoBeam® AC is ideal for CPE deployments requiring maximum performance from the smallest possible footprint.
• Management Wi-Fi Radio
• Improved Surge Protection
• Superior Processing
• Incredible Antenna “Beam” Performance
• Performance Breakthrough
• Advanced Software Technology
• Plug and Play Installation
| 189 x 189 x 125 mm (7.44 x 7.44 x 4.92") |
Weight | 530 g (1.17 lb) |
Enclosure material | UV-stabilized plastic |
Mounting | Pole mount kit (Included) |
Wind loading | 45.4 N at 200 km/h (10.2 lbf at 125 mph) |
Wind survivability | 200 km/h (125 mph) |
Hardware | |
Networking interface | (2) GbE RJ45 ports |
Power method | Passive PoE 2-pair (4, 5+; 7, 8 return) |
Power supply | 24V, 0.5A gigabit PoE adapter (Included) |
Supported voltage range | 20–27V DC |
Max. power consumption | 8.5W |
ESD/EMP protection | Air/contact: ± 24kV |
LEDs | Power, Ethernet, (4) Signal strength |
Salt fog test | IEC 68-2-11 (ASTM B117) |
Vibration test | IEC 68-2-6 |
Temperature shock test | IEC 68-2-14 |
UV test | IEC 68-2-5 at 40° C (104° F) |
Wind-driven rain test | ETS 300 019-1-4 |
Ambient operating temperature | -40 to 80° C (-40 to 176 F) |
Ambient operating humidity | 5 to 95% noncondensing |
Certifications | CE, FCC, IC |
NDAA Compliant | Yes |
System | |
Gain | 19 dBi |
Channel sizes |
|
Max. VSWR | 1.5:1 |
Polarization | Dual linear |
Operating Frequency (MHz) | |
Worldwide | 5150-5875 MHz |
USA |
|
