Ubiquiti Edge Switch XP
EdgeSwitch 5XP is a cost effective, 5-port Gigabit switch with 24V PoE support. The EdgeSwitch 5XP delivers reliable passive PoE and fast 10/100/1000 Mbps connectivity to attached Ubiquiti devices and other devices that support passive
Product Highlights
• Clean Industrial Design
• Convenient PoE Support
• Carrier-Class Reliability
• Industrial-Strength Construction
• A Single Power Source
• Intuitive UI
• Dimensions: 197 x 87.5 x 27.3 mm
• Weight: 250 g
• Power Input : 24VDC, 2.5A Power Adapter (Included)
• Max. Power Consumption: 60 W
• PoE Out Voltage Range: 22-24VDC
• Max. PoE Wattage Per Data Port: 11.5 W
• ESD Rating: 24 kV Air / 24 kV Contact
• PoE Method: Passive
• Button : Reset
• USB Port: 2.0 Type A (Reserved for Future Use)
• Processor : MIPS 24K, 400 MHz
• System Memory : 64 MB
• Code Storage : 8 MB
• Certifications : CE, FCC, IC
• Wall-Mount: Yes
• Operating Temperature: -25 to 55°C (-13 to 131° F)
• Operating Humidity: 90% Non-Condensing
