Ubiquiti Edge Switch X ES-10X
Ideal for WISP applications, the EdgeSwitch® 10X is our most affordable managed switch with SFP ports. Eight Gigabit RJ45 ports offer copper connectivity with PoE input on port 1 and PoE passthrough on port 8. Two SFP ports offer fiber connectivity. The browser-based configuration interface offers intuitive control using a redesigned UI. Management is also available through the Ubiquiti® Network Management System (UNMS™).
Product Highlights
• (8) Gigabit RJ45 Ports
• (2) SFP Ports
• Support PoE Passthrough on Port 8 (software-selectable)
• Powered by 24V Passive PoE or External AC/DC Adapter
• Wall or rack-mountable*
• Dimensions : 207 x 31.1 x 90 mm (8.15 x 1.22 x 3.54")
• Weight: 500 g (1.10 lb)
• Total Non-Blocking Throughput: 10 Gbps
• Switching Capacity: 20 Gbps
• Forwarding Rate: 14.88 Mpps
• Max. Power Consumption (Excluding PoE Output): 8W
• Power Method: 24VDC, 1A or 24V Passive PoE
• Supported Voltage Range: 9 - 30VDC
• Power Supply: 24VDC, 1A Power Adapter (Included) or 24V Passive PoE
• Networking Interfaces: (8) 10/100/1000 Mbps RJ45 Ports (2) 1 Gbps SFP Ports
• Management Interface: Ethernet In-Band
• Certifications: CE, FCC, IC
• Rackmount: Yes*
• ESD/EMP Protection Air: ±24 kV, Contact: ±24 kV
• Operating Temperature: -10 to 50° C (14 to 122° F)
• Operating Humidity: 5 to 95% Noncondensing
• Shock and Vibration: ETSI300-019-1.4 Standard
