Ubiquiti Edge Switch ES-16 (150)
Managed PoE+ Gigabit Switch with SFP
Available with 24 or 48 RJ45 Gigabit ports, the EdgeSwitch® delivers robust performance, PoE+ support and intelligent switching for growing networks.
Product Highlights
• Powerful Enterprise Switch Models
• Enterprise-Class Features
• Optical Fiber Backhaul
• Convenient PoE+ Support
• Breakthrough Value
• Advanced UI
• (16) Gigabit RJ45 Ports
• (2) SFP Ports
• (1) Serial Console Port
• Non-Blocking Throughput: 18 Gbps
• Switching Capacity: 36 Gbps
• Forwarding Rate: 26.78 Mpps
• Maximum Power Consumption: 150W
• Supports POE+ IEEE 802.3at/af and 24V Passive PoE
• Rackmountable with Rack-Mount Brackets (Included)
• Dimensions 443 x 43 x 221 mm (17.44 x 1.69 x 8.70")
• Networking Interfaces: (16) 10/100/1000 Mbps RJ45 Ethernet Ports (2) 1 Gbps SFP Ethernet Ports
• Management Interface: (1) RJ45 Serial Port, Ethernet In/Out Band
• Certifications: CE, FCC, IC
• Rackmount: Yes, 1U High
• ESD/EMP Protection Air: ±24 kV, Contact: ±24 kV
• Operating Temperature: -5 to 40° C (23 to 104° F)
• Operating Humidity: 5 to 95% Noncondensing
• Shock and Vibration: ETSI300-019-1.4 Standard
