Ubiquiti Edge Router 12P
The EdgeRouter 12P is a high performance Gigabit Router with 24V 2-Pair PoE output on each port. With increased performance over the previous generation of routers, the EdgeRouter 12P delivers up to 3.4 million pps for 64-byte packets. Ten Gigabit Ethernet ports offer copper connectivity, while two SFP ports offer fiber connectivity. The EdgeRouter 12P supports Layer-2 switching and scalable configuration using EdgeOS or the Ubiquiti Network Management System (UNMS).
Product Highlights
• The EdgeRouter™ 12/12P offers next-generation price/performance value
• The EdgeRouter 12/12P supports Layer 2 switching
• EdgeRouter 12P supports 24V PoE output on ten RJ45 ports.
• The EdgeRouter 12 can be rack-mounted with the use of the EdgeRouter Rack
• Supported and managed by UNMS™ (Ubiquiti
• Dimensions: 268.1 x 136.5 x 31.1 mm (10.55 x 5.37 x 1.22")
• Weight: 700 g (1.54 lb)
• Max. Power Consumption: 20W (Excludes PoE Output)
• Power Method External: AC/DC Power Adapter, 12W (24V, 2.5A) (Included)
• Power Supply: External AC/DC Adapter
• Supported Voltage Range: 9 - 30VDC
• Button: Reset
• LEDs : Data Ports SFP Data Port Speed/Link/Activity, PoE Link/Activity
• Processor: 4-Core 1 GHz, MIPS64
• System Memory: 1 GB DDR3 RAM
• On-Board Flash Storage: 4 GB eMMC, 8 MB SPI NOR
• Mounting Wall: Rack*
• Operating Temperature: -10 to 40° C (14 to 104° F)
• Operating Humidity: 10 - 90% Noncondensing
