Ubiquiti airFiber X AF-5
Revolutionary Wireless Technology
Introducing airFiber®, a truly revolutionary Point-to-Point wireless platform from Ubiquiti Networks™. Housed in a compact, highly efficient form factor, airFiber delivers amazing wireless gigabit+ performance, low latency, and long range. airFiber ushers in a new era in price-disruptive wireless technology ideal for carrier backhaul, building-to-building enterprise use, or public safety applications.
Product Highlights
• Innovative Antenna Design
• Revolutionary Performance
• Long-Range Links: 100+ km
• Low-Latency Carrier Backhaul
• 5 GHz Unlicensed Band
• Operating Frequency: 5470 - 5600 MHz, 5650 - 5850 MHz (FCC 15.247, 15.407, IC RSS 210)5470 - 5875 MHz (ETSI EN 301 893, EN 302 502) 5470 - 5950 MHz (Other Regions)
• Dimensions: 938.4 x 468.4 x 281.4 mm
• Weight: 16 kg (Mount included)
• Maximum Power Consumption: 40 W
• Power Supply: 50V, 1.2A PoE GigE Adapter (Included)
• Power Method: Passive Power over Ethernet (42-58VDC)
• Certifications: CE, FCC, IC
• Mounting: Pole Mount Kit (Included)
• Wind Loading: 194 lbf @ 125 mph
• Wind Survivability: 125 mph
• Operating Temperature : -40 to 55°C (-40 to 131° F)
• LEDs: (12) Status LEDs
Data Port Link/Activity
Data Port Speed
Management Port Link/Activity
Management Port Speed
GPS Synchronization
Master/Slave
Link Status
Modulation Mode 0.25x to 4x, 6x, 8x, Overload
Remote and Local Displays (Calibrated Signal Strength)
