Alta Labs Route 10
Designed for maximum performance, Route10 includes four autosensing Ethernet ports that support up to 2.5 Gbps Ethernet connections (10/100/1000/2500 Mbps).
• Four 2.5 Gbps RJ45 Ports
• Two Hardware-Accelerated 10 Gbps SFP+ Ports
• Power over Ethernet
• Quad-Core Qualcomm Network Accelerator
• Bluetooth Setup
• Static IP, DHCP and PPPoE WAN Support
• IKEv2 Remote Access
• VLAN and QoS Tagging on WAN Support
• Multiple VLAN and Subnet Support
• mDNS Forwarding
• Firewall Configuration
• NAT Configuration (Source and Destination, Port forwarding)
• UPnP Support
• Dimensions: 180 x 110 x 29.8 mm (7.09 x 4.33 x 1.17")
• Weight: 0.46 kg (1.01 lbs)
• Enclosure Material: Top cover: polycarbonate Bottom cover: milled aluminum
• Material Finish: Matte
• Color: White
• Mount Material: Injection Molded Plastic
• Network Interface
• Ethernet, Bluetooth
• Management Interface
• (4) Autosensing 2500/1000/100/10 Mbps RJ45 Ports,
• (2) 10 Gbps/1.25 Gbps SFP+ Ports
• Data Rate
• 37.5 Million Packets per second
• Power Supply: Universal AC, 100 - 240VAC 50-60Hz External
• Maximum Input Power Consumption: 70W
• Idle Power Consumption: 5W with no connections, 9W with all ports connected
• POE Budget: 40W
• Per-Port PoE: (2) 802.3at POE+, PoE+ (54VDC, 0.6A Max)
• PoE Ports: 2
• Bluetooth Version: BLE
• Total Bluetooth Power: 5 dBm EIRP
• Bluetooth Gain: 3 dBi
