Alta Labs AP6 Pro WiFi 6
The Alta Labs AP6-Pro Access Point features a compact form factor and a sleek aesthetic design allowing seamless integration into corporate, commercial, and residential environments.
• WiFi 6 With WiFi 7 Benefits
• Superior Range and Performance
• 5 GHz: 4x4, DL/UL MU-MIMO, 2.4 GHz 2x2 DL/UL MU-OFDMA
• IP54 Rated
• AltaPass™ Multi-Password Technology
• Scalable Cloud-Based Management
• Mobile App
• DPI Engine
• Hotspot Functionality
• On-The-Fly Changes and Scanning
• SSID Broadcasting Flexibility
• Dimensions 190 x 125 x 32 mm (7.5 x 4.9 x 1.25")
• Weight 0.4 kg (0.9 lbs)
• Enclosure Material Top Cover: Polycarbonate, Bottom Cover: Milled Aluminum
• Mount Material Ceiling/Wall: Polycarbonate, Drop Ceiling: Steel
• Weatherproofing IP54
• Network Interface Ethernet, WiFi, Bluetooth
• Management Interface (1) GbE RJ45 Port
• Button(s) Reset/Factory Reset
• LED Blue, White
• Power Method PoE+
• Power Supply PoE+ Enabled Network Switch or 48V, 0.5A PoE Adapter (Optional)
• Supported Voltage Range 42.5-57V DC
• Power Consumption 25W Max, 7 - 15W Typical @ 23° C (73° F)
• Max. Transmit Power 2.4 GHz: 23 dBm @2NSS, 5 GHz: 26 dBm @4NSS
• MIMO
• 5 GHz: 4 x 4, DL/UL MU-MIMO, DL/UL MU-OFDMA
• 2.4 GHz: 2 x 2. DL/UL MU-OFDMA
• Explicit TX beam-forming
• Throughput Rate 2.4 GHz: Up to 573 Mbps, 5 GHz: Up to 5.8 Gbps
• Antenna Gain 2.4 GHz: Up to 3.3 dBi, 5 GHz: Up to 4.3 dBi
• Mounting Wall, ceiling, drop-ceiling, table top
• Operating Temperature -30 to 60° C (-22 to 140° F)
• Operating Humidity 5 to 95% Noncondensing
• Certifications CE, FCC, IC (Visit Alta.inc for a full list of certifications)
