Ubiquiti UISP Console
UISP host console with an integrated switch and multi-gigabit Ethernet gateway.
| 210.4 x 140.2 x 43.7 mm (8.3 x 5.5 x 1.7") |
Weight | 1.5 kg (3.2 lb) |
Enclosure materials | SGCC steel, polycarbonate |
Hardware | |
Processor | Quad-core ARM® Cortex®-A57 at 1.7 GHz |
Memory | 4 GB DDR4 |
Onboard flash storage | 16 GB eMMC |
Onboard storage | 128 GB SSD |
Card slot | (1) microSD (Up to 2TB) |
Networking interface | (8) LAN: GbE RJ45 ports |
Management interface | Ethernet In-band |
Power method | (1) External AC/DC adapter |
Power supply | 24V DC, 2.5A power adapter (included) |
Supported voltage range | 24—28V DC |
Max. power consumption | 30W |
ESD/EMP protection | Air: ± 15kV, contact: ± 8kV |
Ambient operating temperature | -10 to 50° C (14 to 122° F) |
Ambient operating humidity | 5 to 95% noncondensing |
Certifications | CE, FCC, IC |
NDAA Compliant | Yes |
LEDs | |
System | Status |
RJ45 data ports | Speed/link/activity |
SFP+ data ports | Speed/link/activity |
