Ubiquiti Network Video Recorder
A video recorder with (4) 2.5/3.5" HDD bays that can support up to 30 days of storage for (18) 4K cameras or (60) Full HD cameras.
• Dimensions: 442 x 325 x 44 mm
• (17.4 x 12.8 x 1.7"): UniFi Application Suite
• Protect: ✓
• Access: ✓
• Managed Cameras: (60) HD
• (30): 2K
• (18): 4K
• Storage Capacity: (4) 3.5" drive bays
• Data Protection: ✓
• Vantage Point: ✓
• Networking Interface: (1) 10G SFP+
• (1): GbE
• Power Redundancy: ✓
• Form Factor: Rack mount (1U)
• Door Access Support: ✓
Hardware
• Hard Drive Capacity: (4) 2.5/3.5” HDD / SSD support
• Max. Power Budget for Drives: 75W
• Max. Power Consumption: 100W
• Power Method: (1) Universal AC input, 100—240V AC, 2A Max., 50/60 Hz
• (1) USP-RPS DC input, 11.5V DC, 10.43A
• Power Supply: AC/DC, internal, 120W
• Processor: Quad ARM® Cortex®-A57 cores at 1.7GHz
• Memory: 4GB
• Management: Ethernet
• Weight
• Without mounting brackets: 5.1 kg (11.3 lb)
VWith mounting brackets: 5.2 kg (11.5 lb)
• Enclosure Material: SGCC steel
• Mount Material: SGCC steel
• Ambient Operating Temperature: -5 to 40° C (23 to 104° F)
• Ambient Operating Humidity: 5 to 95% noncondensing
• VNDAA Compliant: ✓
• VCertifications: CE, FCC, IC, SRRC
